S31-D active subwoofer

MODEL:S310-D

Type:Active subwoofer system

Drivers3 x 10 inches

Active speaker: One 10 inch LMF ultra-low distortion anodic alumina basin horn

Passive speakers: two 10 inches planar honeycomb sandwich carbon fiber passive speakers

Power Handling:500W Max SPL output(1m):116dB

Input voltage: 100-240V AC (switch 100-120V AC or 220-240V AC)

Input/Output port: XLR balanced input x 1 / XLR output x 1

1 for RCA stereo input /1 for RCA stereo output

Frequency response (±3dB):25Hz-350Hz Impedance:22K

Product dimensions: H 350 x W 350 x D385 mm ((w/o foot)

H 380x W 350 x D385 mm ((w/foot)

Shipping size: 475*450*485 (mm/H*W*D)

Weight: 19.00/41.89(kg/lb)

Shipping Weight:21.50/47.40(kg/lb)

Category:

Description

MODEL:S310-D

Type:Active subwoofer system

Drivers3 x 10 inches

Active speaker: One 10 inch LMF ultra-low distortion anodic alumina basin horn

Passive speakers: two 10 inches planar honeycomb sandwich carbon fiber passive speakers

Power Handling:500W Max SPL output(1m):116dB

Input voltage: 100-240V AC (switch 100-120V AC or 220-240V AC)

Input/Output port: XLR balanced input x 1 / XLR output x 1

1 for RCA stereo input /1 for RCA stereo output

Frequency response (±3dB):25Hz-350Hz Impedance:22K

Product dimensions: H 350 x W 350 x D385 mm ((w/o foot)

H 380x W 350 x D385 mm ((w/foot)

Shipping size: 475*450*485 (mm/H*W*D)

Weight: 19.00/41.89(kg/lb)

Shipping Weight:21.50/47.40(kg/lb)

Product features:

Uncompromising compact high energy subwoofer

More popular with consumers exquisite volume, uncompromising extreme low frequency extension

(as low as 25Hz), peak 1500W class-D (RMS 500W) digital audio amplifier, built-in precision

DSP processing circuit, RCA stereo input, XLC balanced INPUT and output.

The new S310-D is a compact, yet powerful subwoofer that has everything audiophile is looking for.

S310 -d subwoofer, USES a 10-inch LMF ultra-low distortion anodic alumina basin unit, with two

 10 inches planar honeycomb sandwich carbon fiber passive unit, ensure the minimum distortion

conditions play cinema and music acme dynamic, has the abundant energy, low descend, strong force

and elasticity, as well as good sound clarity.

Power amplifier is the industry-leading class-D digital audio amplifier circuit, LLC resonant soft

switching power supply, with high conversion efficiency, low temperature rise, low ripple noise,

large power density, fast dynamic response, stable voltage output characteristics; At the same time,

 high speed pressure limiter is used to avoid distortion caused by high output of power amplifier.

 Strong overload capacity, sufficient power reserve, with better dynamic characteristics, instant

 response, full sense of bursting.
